Features
-Real-Time CPU Temperature Display
-3-Phase Sensorless motor
-Low-Thermal Resistance cooling
-Pure Copper Base Contact Plate
-Ceramic Shaft and Bearings
-Universal Intel and AMD mounting

UNIQUE COOLING FAN
9 Blade cooling fan equipped with anti-vibration pads provides supreme efficiency

COLD EXHAUST
All-aluminum high-density, miniature water channel plate to maintain low resistance, wide wave belt cooling surface to enhance the cooling efficiency.

COPPER BAYSWATER BLOCK
The water block is made of pure copper and boasts high thermal conductivity, keeping the temperature of the CPU stable and enabling higher levels of overclocking.

PERFECT AND STABILITY PERFOMANCE
Stability, lifespan and performance have been greatly increased through the use of pumps with strong corrosion resistance and heat resistance, long-life ceramic bearings, product-specific dual structure design, and optimal impeller structure.

Specifications
Radiator size: 276 × 120 × 27mm
Water block size: 70 × 70 × 55.5mm
Pipe type: Black rubber with braided mesh, 400mm
Cover material: PC, black spray coated
Base plate: Copper, 62 × 54 × 2.5 mm
Pump motor: Brushless 3-phase sensorless
Pump rated voltage: 12V DC, 4.2W ±10%, 0.35A ±10%
Pump speed: 2650 ±10% RPM
Noise level: ≤30 dB
Product lifetime: 30,000 hours @25°C

DIGITAL DISPLAY MODULE
Size: 34.1 × 40 × 6.6 mm
Voltage: 5V DC
Power: 2.3W
Current: 460mA
Operating temp.: -20~60°C
Storage temp.: -40~80°C
Display color: Bright white

FAN SPECIFICATIONS
Size: 120 × 120 × 25 mm (×2)
Fan speed: 800~2000 RPM
Rated voltage: 12V / 0.25A
Noise level: ≤32.5 DBA
ARGB voltage: 5V / 0.12A / 0.6W
Bearing type: Hydraulic
Material: PBT frame + PC blades
